CNC Lathe Features:Four-station electric knife holderFrequency stepless speed regulationStandard configuration: manual chuckChoose configuration: spring collet，hydraulic chuck,Automatic feeding device, row knife holder.Standard AccessoriesOptional AccessoriesFrequency Spindle;200mm 3-jaw Manual Chu
| PECIFICATIONS | Units | CK6140 |
| Swing over bed | mm | 400 |
| Swing over cross slide | mm | 200 |
| Distance between centers | mm | 750/1000/1500/2000 |
| Spindle bore | mm | 52(Optional 80) |
| Spindle bore taper | - | MT5 |
| Spindle nose type | - | A2-6 |
| Spindle speed steps | - | stepless |
| Spindle speed range | rpm | 50-2000 |
| Turret/tool post | - | Electric 4 position |
| Tool size | mm | 20*20 |
| X axis travel | mm | 240 |
| Z axis travel | mm | 750/1000/1500/2000 |
| X axis rapid traverse | mm/min | 6000 |
| Z axis rapid traverse | mm/min | 8000 |
| Tailstock quill diameter | mm | 60 |
| Tailstock quill taper | - | MT4 |
| Tailstock quill travel | mm | 130 |
| Main spindle motor | kw | 5.5 |
| Coolant pump motor | kw | 0.09 |
| Weight for 750 | kg | 1700 |
| Weight for 1000 | kg | 1800 |
| Weight for 1500 | kg | 1900 |
| Weight for 2000 | kg | 2000 |
| Dimension （L*W*H） | mm | 2150/2400/2900/3400*1500*1650 |
CNC Lathe Features:
Four-station electric knife holder
Frequency stepless speed regulation
Standard configuration: manual chuck
Choose configuration: spring collet，hydraulic chuck,Automatic feeding device, row knife holder.
| Standard Accessories | Optional Accessories |
Frequency Spindle; 200mm 3-jaw Manual Chuck; 4 station turret; Manual Tailstock; Full-splash Guard Stepless speed change. | Hydraulic Chuck; Hydraulic tailstock; step speed change by manual; Auto 3-step speed change; 6/8/12-station turret; Center Rest and follow rest; 4-Jaw chuck. Living tools |
